G80 Hammerlock Chain Connector - Type CL
101806
Regular price
$10.93
10 available
- Austlift brand.
- Use chain connectors to create custom chain assembly.
- Commonly used to connect head rings, chain, hooks and other lifting components.
- Marked with:
- Chain size
- Grade
- Brand
- Made from high quality G80 alloy steel with a safety factor of 4 to 1.
- Conforms to AS3776.
- Dimensions (mm):
- 101806: B - 15, C - 42, D - 7, E - 18, W - 43.
- 101808: B - 18, C - 60.5, D - 8.5, E - 23.5, W - 55.
- 101810: B - 25, C - 68, D - 11.5, E - 27, W - 69.
- 101813: B - 29, C - 87, D - 15, E - 32, W - 83
- Working Load Limit:
- 101806: 1120kg
- 101808: 2000kg
- 101810: 3200kg
- 101813: 5300kg
